3M™ DI-NOC™ Architectural Finishes PA-175, 4 ft x 164 ft

3M ID  JR420048506
DI-NOC Pattern - PA-175, flat
3M™ DI-NOC™ Architectural Finishes are decorative surface finishes available in 500+ designs at a budget-friendly price. 3M DI-NOC designs offer the warmth of wood grain. The sleek feel of metal. The cool of natural stone. Specify them and you won't think faux - you'll think, fantastic.
  • Aesthetics - DI-NOC architectural finishes resemble natural materials and other types of surfaces to an astonishing degree. They deliver the look you want, at the price you need.
  • Remodel and Reuse - They go up fast, with less likelihood of error and waste, and bring life to existing assets.
  • Easy Application - 3M Comply™ Adhesive Technology is repositionable and virtually eliminates bubbles, simplifying and speeding application. Yet if bonds powerfully to many substrates.
Need Help?

Questions? We can help

Contact Us

Add a Sample

Overview

You should insist on DI-NOC™ Architectural Finishes because it is lightweight and self-adhering, and can be applied on site to the exsisting substrate, reducing labor and material cost compared to natural materials. With DI-NOC™ products, you create a whole new look, quickly and inexpensively, but not at the expense of aesthetics, thanks to its uncanny resemblance to natural materials. Use this product for both renovations or new construction.
  • Walls and wall panels
  • Ceilings
  • Fixtures
  • Elevators
  • Doors
  • Columns
  • Furniture
  • Backlit
  • Partitions
  • Curved surfaces
  • Flat surface - high gloss designs

Specifications

Adhesive Color Clear
Adhesive Controltac/Comply Comply™
Adhesive Type Pressure-sensitive
Applications Ceilings, Furniture, Lobbies and elevators, Partitions, Walls
Application Method Dry Application
Application Recommendations Can not be applied on PVC coated substrates.
Application Temperature +15°C to +38°C minimum (air and substrate)
Approval/Certification Flammability & IMO standards
Brand DI-NOC
Design Pattern PA-175
Design Pattern PA-175
Film Type Vinyl
Length 164 Linear Foot
Length (Metric) 50 Linear Metre
Liner PE coated kraft paper
Max. Warranty Exterior 5 years
Max. Warranty Interior 12 years
Opacity Opaque
Performance Level Premium
Product Code PA-175
Product Family Metallic
Product Line DI-NOC Architectural Surfaces Finishes
Removability Permanent
Surface Finish Matte
Surface Type 3 Dimensional, Flat
Thickness (film) 210-220 µm
Usage Interior
Width 4 Linear Foot
Width (Metric) 1.22 Linear Metre
