3M™ Adhesive Transfer Tape Extended Liner 920XL is a 1.0 mil, general purpose, extended liner, pressure sensitive acrylic adhesive transfer tape ATT with a densified kraft paper liner. Acrylic Adhesive 400 family.
1 mil adhesive with an off-wite densified kraft paper printed liner with statement, Remove To Expose Adhesive
Dry edge, finger lift edge, convenience. Easy liner starting and removal. Ideal for automated tape application equipment. Tack free tape roll edges for ease of use and reduced equipment maintenance.
General purpose adhesive transfer and double coated tapes with extended liners used on a variety of high surface energy and low surface energy HSE LSE materials such as coated and uncoated papers, films, plastics, foams and metals.
Pharmaceutical, Medical, Paper and Print, Commercial Printing, Packaging, POP Point of Purchase, General Industrial
Used for sealing, splicing, bonding, mounting, attaching, holding, affixing, joining, and laminating. Paper to paper applications, small packaging, pharmaceutical outserts, seals flaps on bags or envelopes. Used on high speed presses, collators and tape application equipment.
Used for pharmaceutical outsert attachment, general paper attachment, and for applications requiring a thinner liner. Use to seal flaps on poly-bags and envelopes. Pressure sensitive edging on business forms, literature, photos, posters, and labels.
Specifications
Adhesion to Foam
4
Adhesion to HSE
Medium
Adhesion to LSE
Low
Adhesion to Metal
Medium
Adhesive Peel Initial
4
Adhesive Peel Ultimate
5
Brand
3M
Chemical Resistance
6
China RoHS - Below MCV
Yes
Color
Translucent
EU RoHS Compliant
Yes
Face-Side Adhesive Type
400 High Tack Acrylic
Humidity Resistance
8
Industry - Use
General Industrial, Medical, Packaging, Paper, Print, Retail
