3M™ Adhesive Transfer Tape 9499 Clear, 3/4 in x 60 yd 2.0 mil, 48 per case Bulk

UPC# 00021200671500    3M Product Number 9499    3M ID 70006089687
High Temperature Adhesive Transfer Tape 9499
2.0 mil, transparent acrylic adhesive 430 with 3.5 mil 60 lb densified kraft liner
  • High temperature splicing adhesive transfer tape
  • High tack, excellent adhesion to most paper stocks. Good low temperature performance and peel strength on many surfaces.
  • General purpose adhesive transfer tapes for use in printing applications such as splicing, core starting, flexo, and laminating. Zero speed splicing applications.
  • Paper and Print, Commercial Printing, General Industrial
  • Used for core starting, splicing, bonding, mounting, attaching, holding, affixing, joining, and laminating. Paper to paper applications and flexo printing. General purpose 2 mil tape.
    		•
    Need Help?

    Questions? We can help

    Contact Us

    Overview

    Support
    High air heat (oven) resistance *Ideal for zero speed splicing of most grades of paper *Good solvent resistance

    Specifications

    Adhesion to Foam 4
    Adhesion to HSE 6
    Adhesion to LSE 5
    Adhesion to Metal 6
    Adhesive Peel Initial 3
    Adhesive Peel Ultimate 4
    Adhesive Type 430 High-Tack Acrylic
    Brand 3M
    Chemical Resistance 5
    China RoHS - Below MCV Yes
    Color Clear
    Construction Single Coated
    EU RoHS Compliant Yes
    Face-Side Adhesive Type 430 Acrylic Adhesive
    Humidity Resistance 10
    Industry - Use General Industrial, Paper, Print
    Length 60 Linear Yard
    Length (metric) 54.86 Linear Metre
    Liner Color Tan
    Liner Thickness 3.5 Milli-inch (mil)
    Master Size Length 360 Linear Yard
    Master Size Width 48 Inch
    Maximum Operating Temperature (Fahrenheit) 350 Degree Fahrenheit
    Minimum Operating Temperature (Fahrenheit) -40 Degree Fahrenheit
    Moisture Resistance 10
    Nominal Adhesive Thickness (mils) 2 Milli-inch (mil)
    Plasticizer Resistance Low
    Primary Liner 60# Densified Kraft Paper
    Product Form Roll
    Shear Strength at 72 Degrees F (22 Degrees C) 10 Pound-Force Per Square Inch
    Solvent Resistance 5
    Thickness 2 Milli-inch (mil)
    Thickness (metric) 0.05 Millimetre
    Units per Case 48
    UV Resistance High
    Width 0.75 Inch
    Width (metric) 19.05 Millimetre
