3M™ DI-NOC™ Architectural Finish WG-156 Wood Grain (1.22 m x 12 m)

3M ID  JR420075608
DI-NOC Pattern - WG-156, flat
DI-NOC Pattern - WG-156, flat
DI-NOC Pattern - WG-156
3M™ DI-NOC™ Architectural Finishes are used by designers and architects around the world as decorative material. Those finishes give you almost unlimited creative freedom, whilst its ability to be converted in situ affords cost effective refurbishment and repair. The "Wood Grain" family contains patterns with a natural repeat and grain pattern for a authentic wood look.
Need Help?

Questions? We can help

Contact Us

Add a Sample


Overview

3M™ DI-NOC™ Architectural Finishes are used by designers and architects around the world as decorative material. Available in more than 600 designs, colors and textures, those finishes give you almost unlimited creative freedom, whilst its ability to be converted in situ affords cost effective refurbishment and repair. Suitable for both indoors and outdoors. The finishes offer a new way to communicate and express your message within interior and exterior designs for both refurbishment and new construction. Interpret your space and create a unique visual experience.

Specifications

Adhesive ColourClear
Adhesive TypePressure-sensitive
Application RecommendationsCan be applied on PVC coated substrates. Do not conduct butt-join method and apply with reveals or joint separations.
ApplicationsCeilings, Furniture, Lobbies and elevators, Partitions, Walls
Application Temperature (C)+15°C to +38°C minimum (air and substrate)
Design PatternWood Grain
Length12 m
Max. Warranty Exterior5 years
Max. Warranty Interior12 years
OpacityOpaque
RemovabilityPermanent
Removal MethodRemovable with a heat gun at 80°C – 100°C.
Repeat Pattern Height1300 mm
Repeat Pattern Width595 mm
Surface FinishMatte
Surface Pattern/GrainMixed
Surface Type3 Dimensional, Flat
Thickness (film)210-220 µm
UsageExterior, Interior
Width1.22 m
Wood TypeTamo
